Roland EC-10 EL Cajon Mic Processor

Make your cajon sound larger than life with the Roland EC-10M ElCajon Mic Processor. It's an easy-to-use processor that mixes the natural sound of your cajon with a variety of onboard tones, creating a layered percussion sound you can send to an amplifier or PA system. Just attach the clip-on condenser mic to your cajon, select a sound to layer with your cajon, and you're set. Use the built-in looper for practice or performance. Play additional sounds with the integrated footpads, or trigger sounds via optional trigger pedals and pads (not included).





Roland EC-10M ElCajon Mic Processor Features at a Glance:

• Microphone preamp and processor for cajon
• Clip-on condenser mic captures the natural sound of your cajon
• Layer a variety of onboard sounds, including 16 kits with sounds like tambourine, shaker, djeme, electronic drums and more
• Responds to the edge and head of your cajon separately, allowing you to trigger two different onboard sounds
• Trigger onboard sounds using the A/B foot pads
• Connect up to two kick trigger pedals or pads (sold separately) to play additional sounds
• Built-in looper is great for practice or performance
• Send your cajon mic and layered sounds separately, or mix them both to a mono output
• Can be powered via included power supply or 4 x AAA batteries (not included)



ENHANCE YOUR ACOUSTIC CAJON PERFORMANCES

With the EC-10M, it’s easy to take your acoustic cajon performances to new heights. Just attach the dedicated clip-on mic to the instrument’s sound hole, and then layer EC-10M tones with the acoustic voice to create unique hybrid sounds. The 16 kit variations include percussion sounds such as tambourine, surdo, splash cymbal, and many others, plus acoustic snare drum and the famous TR-808 snare. Built-in cajon tones with ambience are also included for reinforcing your acoustic cajon’s natural voice with powerful studio sound.



ADD VARIETY AND PLAY WITH AUTHENTIC CAJON TECHNIQUES

The EC-10M intelligently senses when the mic is picking up sounds from the head and edge surfaces on the cajon, giving you the ability to trigger distinctly different electronic sounds with each of these areas. This lets you integrate EC-10M sounds using authentic cajon techniques, so you don’t have to adjust your playing in any way.



TRIGGER EXTRA SOUNDS WITH FOOT PADS OR OPTIONAL PEDALS

In addition to head and edge sounds, each of the 16 kits within the EC-10M includes two electronic sounds that are pre-assigned to the onboard A/B foot pads for triggering with toe taps while performing. If you’d prefer to play these sounds with authentic foot techniques and a more solid feel, up to two Roland kick trigger pedals (KT-10, KT-9, or KD-7) can be connected.*

*A splitter cable (such as the optional PCS-31L) is required to connect two kick trigger pedals to the EC-10M.



LIGHT, COMPACT, AND BATTERY-POWERED

You can use the compact EC-10M anywhere, since it weighs just 500 g/1.1 lbs. and runs on four AAA batteries. The included clip-on condenser mic is compact and convenient, eliminating the need to take up valuable stage space with a mic stand and large microphone. With its small footprint, the EC-10M is an easy fit in the tightest performing spaces.



AMPLIFY YOUR ACOUSTIC CAJON AND EC-10M LAYERED SOUNDS

Along with being a sound module for electronic sounds, the EC-10M also functions as a mic preamp for the clip-on mic, enabling you to amplify both the acoustic cajon and layered sounds through an amp or PA. You can send the sounds to two independent outputs, or mix them together to one. With the EC-10M, it’s simple to achieve a powerful, consistent cajon sound at every gig, from intimate street performances to the biggest concert stages.



RECORD PERCUSSION PHRASES AND PLAY ALONG

The EC-10M includes a built-in looper* for the electronic layered sounds. This lets you create instant percussive backing for acoustic cajon playing or jamming with another instrument. The looper is controlled using the A/B foot pads, and you can capture electronic sounds triggered from the cajon and external pedals in your loops. And by changing the kits while the loop is playing, the tones in the loop are changed too. With this cool creative option, your acoustic cajon performances will be transformed forever!

*Recorded phrases cannot be saved.



SPECIFICATIONS:



Sound Kit Variation

16



Layered Sound Contents

2 (High, Low)



Controls

[Top Panel]
POWER switch
(MIC) COMPRESSOR knob
(MIC) VOLUME knob
(ELECTRONIC) THRESHOLD knob
(ELECTRONIC) VOLUME knob

MODE SELECT button

A button
B button

[Left Side]
MIC GAIN knob
ENHANCE switch



Indicators

KIT Number



Connectors

TRIGGER INPUT jack: 1/4-inch TRS phone type
MIC INPUT jack: Stereo miniature type (Use included clip mic only)
MIC/MIX OUTPUT jack (MONO): 1/4-inch phone type
ELECTRONIC OUTPUT jack (MONO): 1/4-inch phone type
DC IN jack



Power Supply

AC adaptor (DC5.7V)
Rechargeable Ni-MH battery (AAA, HR03) x 4



Current Draw

150 mA



Expected battery life under continuous use

Approx. 5 hours.
* These can vary depending on the specifications of the batteries, capacity of the batteries, and the conditions of use.



Accessories

Clip Mic
Owner's manual
Leaflet "USING THE UNIT SAFELY"
AC adaptor



Options (sold separately)

Kicks: KD-7, KT-9, KT-10
Stereo Split Cable: PCS-31L
